GIGABYTE B850 GAMING X WIFI6E (rev. 1.x)

X3D Turbo Mode's unique optimization parameters allow even Ryzen™ 9000 X3D gaming Performance enhance & Ryzen™ 9000 non-X3D processors to achieve similar gaming performance levels as their Ryzen™ X3D counterparts. Experience smoother gameplay, higher frame rates, and reduced latency with GIGABYTE's BIOS innovation- X3D Turbo Mode.

One-Click Acceleration :

Enhance Gaming FPS Performance with a single click.

Enhance Up to 18%

Our cutting-edge motherboard is designed for the ultimate DIY experience. Creating your own PC becomes a delightful and smooth process.

Wifi EZ Plug and EZ-Latch design for user friendly access to Wifi and M.2 drives

CPU
AMD Socket AM5, support for:
AMD Ryzen™ 9000 / 8000 / 7000 Series Processors
(Refer to GIGABYTE's website for the latest CPU support list.)

Chipset
AMD B850

Memory

• Support for DDR5 8200(O.C)/8000(O.C)/7950(O.C)/7900(O.C)/7800(O.C)/7600(O.C)/7400(O.C)/7200(O.C)/7000(O.C)/6800(O.C)/6600(O.C)/6400(O.C)/6200(O.C)/6000(O.C)/5800(O.C)/5600(O.C)/5200/4800/4400 MT/s


• 4 x DDR5 DIMM sockets, up to 256 GB (64 GB per DIMM)


• Dual channel memory architecture


• Non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 support


• AMD EXPO™ and XMP memory support


• (CPU and memory configuration may affect supported memory types and speeds)



Onboard Graphics

• Integrated AMD Radeon™ Graphics


• 1 x DisplayPort, max 3840x2160@144 Hz (DisplayPort 1.4, HDR)


• 1 x Front HDMI, max 1920x1080@30 Hz (HDMI 1.4)



Audio

• Rev. 1.0: Realtek® Audio CODEC, 2/4/5.1/7.1-channel, S/PDIF Out


• Rev. 1.1: Realtek® ALC1220 CODEC, 2/4/5.1/7.1-channel, S/PDIF Out, DSD support



LAN

• Realtek® 2.5GbE LAN



Wireless

• Realtek® Wi-Fi 7 RTL8922AE, 802.11a/b/g/n/ac/ax/be, 2.4/5/6 GHz, Bluetooth 5.4, 11be 160MHz


• Wi-Fi 7 features require Windows 11 SV3


• 6 GHz band availability depends on local regulations



Expansion Slots

• 1 x PCIe x16 (CPU): Ryzen™ 9000/7000 = PCIe 5.0 x16, Ryzen™ 8000 Phoenix1 = PCIe 4.0 x8, Phoenix2 = PCIe 4.0 x4


• 2 x PCIe x16 (chipset, x1 mode)



Storage

• 1 x M.2 (M2A_CPU) PCIe 5.0/4.0 x4/x2 depending on CPU


• 1 x M.2 (M2B_CPU) PCIe 4.0 x4/x2 depending on CPU


• 1 x M.2 (M2C_SB) PCIe 4.0 x4/x2


• 4 x SATA 6Gb/s


• RAID 0/1/5/10 for NVMe (RAID 5 only Ryzen™ 9000)


• RAID 0/1/10 for SATA



USB

• CPU: 1 x USB-C 3.2 Gen2, 2 x USB-A 3.2 Gen2 (red)


• CPU + Hub: 4 x USB 2.0/1.1


• Chipset: 1 x USB-C 3.2 Gen2x2, 3 x USB 3.2 Gen1, 4 x USB 2.0/1.1


• Chipset Hub: 4 x USB 3.2 Gen1



Internal I/O Connectors

• 24-pin ATX, 8-pin + 4-pin ATX 12V


• CPU fan & pump headers, system fan & pump headers


• 3 x addressable RGB Gen2, 1 x RGB LED header


• 3 x M.2 slots, 4 x SATA


• Front panel, audio, USB-C Gen2x2, USB 3.2 Gen1, 2 x USB 2.0/1.1, TPM header


• HDMI (CPU dependent), power button, reset button, reset jumper, Clear CMOS



Back Panel Connectors

• 1 x DisplayPort*, 1 x HDMI*


• Q-Flash Plus button


• 4 x USB 2.0/1.1, 5 x USB 3.2 Gen1, 2 x USB 3.2 Gen2 (red), 1 x USB-C 3.2 Gen1


• RJ-45, 2 x antenna (2T2R), 2 x audio jacks, 1 x optical S/PDIF



I/O Controller

• iTE® I/O Controller



H/W Monitoring

• Voltage, temperature, fan speed, water pump flow, fan fail warning, fan speed control



BIOS

• 256 Mbit flash, AMI UEFI BIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0



Unique Features

• GIGABYTE Control Center (GCC), Q-Flash, Q-Flash Plus, Smart Backup



Bundled Software

Norton® Internet Security, LAN bandwidth management software

Operating System Support

• Windows 11 64-bit
• Windows 10 64-bit

Form Factor

• ATX, 30.5 x 24.4 cm

3 year warranty

GIGABYTE AMD B850 Gaming Chipset for AMD AM5
